Atauff AHF04 flat-face quick release coupling, ISO 16028 / 350 Bar, radial ball locking.
| Standard | ISO 16028 (DN06 → DN30) |
|---|---|
| Occlusion | Flat face |
| Locking | Radial balls |
| Material | Steel |
| Finishing | Zn-Fe (Cr III) and Zn-Ni |
| Threads | BSP-NPT |
| Standard seals | NBR and PU (FKM, EPDM or more optional) |
| Working temperature | -25°C to +100°C |
| Working pressure | 350–500 Bar |
| Connection under residual pressure | Not allowed |
Get pricing, availability and product details from Western Hardware Mart.
Quick disconnect coupling for fast connection/disconnection of hydraulic lines. Offers unrestricted flow when connected and is designed to avoid premature flow before the coupling is fully closed.
ISO A couplings made to ISO 7241:2014 Series A standard (Atauff AH Series). Suited to agricultural and industrial applications.
